The Sentry® SLQC is designed for use with our 200 liter FluoroPure® Asia HDPE blowmolded and HDPEsmall diameter blowmolded drums. These high purity chemical packaging solutions provide greater adaptability to a broad range of delivery systems.
The Sentry SLQC provides a faster connection than traditional designs and is suitable for one-way or multi-use applications, including:
- High-purity, corrosive chemical handling
- Ideal for high flow chemical distribution applications
Specifications
Downtube/Drum | |
Connection: | 2" buttress thread |
Transport approvals: | DOT/UN Group II |
UN Approvals: | |
Asia HDPE Blowmolded Drum | UN 1H1/Y1.9/170 TW/EPT-CR6001 UN 1H1/Y1.9/300 TW/EPT-CR6002 |
Asia Standard HDPE Blowmolded Drum | UN 1H1/Y2.0/170/2006 TW/EPT-CR6003 |
Materials: | Polyethylene |
Dispense Adapter: | |
Drum connection: | Buttress thread with Flaretek flared seal |
Fill/dispense adapter thread: | 3/4" FNPT (other sizes available) |
Vent adapter thread: | 1/2" FNPT (other sizes available) |
Materials: | All wetted parts are PTFE, nonwetted polyethylene and ECTFE |
Typical flow: | CV 8 (KV 114) |
Successfully Opted for software Updates
Part Number | Product Type | Drum Closure Use | Downtube |
---|---|---|---|
SLDAE-12F | QC dispense adapter | N/A | N/A |
SLDC-101 | Drum closure assembly | Dispense | Fits FluoroPure® Asia 200 liter HDPE blowmolded drum |
SLDC-102 | Drum closure assembly | Dispense | Fits FluoroPure® Asia Standard 200 Liter HDPE blowmolded drum |
SLDC-200 | Drum closure assembly | Vent | No downtube |
SLVAE-08F | QC vent adapter | N/A | N/A |
